Infitek Laser is a leading Manufacturer, Supplier and Exporter of Fiber Laser Jewellery Engraving Machine in Ahmedabad, Gujarat, India.
Our manufacturing unit is based in Ahmedabad, Gujarat, India.
A fiber laser jewellery engraving machine is a laser-based system that uses a concentrated beam of light to mark or engrave suitable metal surfaces.
Depending on the laser settings, material, and application, it can produce fine text, logos, decorative patterns, serial numbers, and personalized messages.
Unlike conventional mechanical engraving, laser marking is a non-contact process. The laser interacts with the material surface without requiring a cutting tool to touch the jewellery directly.
We provide jewellery-specific fiber laser systems that support a range of marking requirements, from customized ornaments to production-oriented applications.
Key Features That Support Detailed Jewellery Work:
- Fine engraving capability: Creates detailed text, symbols, logos, and decorative patterns.
- Multiple laser power options: Available configurations include 20W, 30W, 50W, 60W, 80W, and 100W fiber lasers.
- Flexible marking areas: Different field sizes accommodate varying design and component dimensions.
- Digital design compatibility: Supports graphics through EZCAD software and listed formats such as PLT, DXF, BMP, JPG, and TIF.
- Adjustable Z-axis: Manual or automatic movement options help position different workpieces.
- Contactless processing: The laser marks the surface without requiring a cutting or engraving tool to touch it.
- Production consistency: Saved designs and controlled parameters help reproduce markings across multiple pieces.
Specifications of Fiber Jewellery Machine:
| Parameter | Specification |
|---|---|
| Fiber Laser Power | 20W, 30W, 50W, 60W, 80W, 100W Galvo Type |
| Co2 Laser Power | 30W, 50W, 80W, 100W Galvo Type |
| Z-Axis | Manual operated / Auto operated |
| Marking Area | 7070mm, 110110mm, 150150mm, 175175mm, 200mm200mm, 250250mm, 300*300mm |
| Co2 Laser Brand | EFR, Reci, Davi |
| Fiber Laser Brand | IPG, Raycus, JPT, MAX |
| Software | Ezcad |
| Graphics Format | PLT, DXF, BMP, JPG, TIF |
| Temperature | Up to 32 degree C |
| Input power | AC 220V±22V 50Hz/60Hz 32A, Single Phase |
Why Fiber Laser Technology Makes a Difference?
Compared with many traditional manual marking methods, fiber laser technology offers a digitally controlled approach to jewellery engraving.
1. Repeatable detailing
Useful for reproducing the same design across multiple items.
2. No engraving tool wear
The marking process does not rely on a physical engraving bit.
3. Compact workstation options
Suitable configurations can fit jewellery workshops and specialized production areas.
4. Flexible applications
One system can support several types of marking jobs, depending on material compatibility.
5. Reduced consumable requirements
Laser marking generally does not require engraving ink or marking chemicals.
6. Scalable production
Businesses can choose laser power and marking-area options to suit their workload.
Frequently Asked Questions:
1. What is a fiber laser jewellery engraving machine?
It is a digitally controlled machine that uses a focused fiber laser beam to mark or engrave compatible metal jewellery with text, logos, symbols, and decorative designs.
2. Can a fiber laser machine engrave gold and silver?
Yes, suitable fiber laser configurations can mark gold and silver jewellery. The results depend on the alloy, surface finish, laser settings, and desired marking effect.
3. What laser power is suitable for jewellery engraving?
Infitek Laser lists fiber laser options from 20W to 100W. The right power depends on the required detail, marking depth, material, and production volume.
4. Can the machine engrave names and logos on rings?
Yes, it can create personalized names, initials, and logos on compatible rings. Curved surfaces may require suitable fixtures or a rotary attachment.
